Full Product Description
The RANMEI Waterproof Rocker Switch is a heavy-duty solution for managing high-draw accessories like LED light bars, fog lights, winches, or bilge pumps. While many standard rocker switches are limited to 15 or 20 amps, these are rated for 30A DC, allowing them to handle more powerful equipment without overheating.
The round snap-in design makes installation straightforward; simply drill a 12mm (0.47″) hole and press the switch into place. The terminals are silver-plated for maximum conductivity, and the package includes a protective rubber boot to achieve an IP65 waterproof rating, making them a favorite for marine dashboards and off-road truck panels.
Key Features & Benefits
-
High Load Capacity: Rated for 30 Amps at 12V DC, significantly higher than typical 20A consumer switches.
-
Integrated Blue LED: Built-in light provides clear “active” status and helps you locate the switch in the dark.
-
Weatherproof Design: Includes a flexible rubber cover to protect internal components from water, dust, and grime.
-
Compact Footprint: Fits into standard 12mm (approx. 1/2″) mounting holes, ideal for crowded dashboards or custom panels.
-
Safe Construction: Made with flame-retardant materials and high-conductivity brass/silver-plated pins.
-
Versatile Application: Perfect for DIY custom wiring in motorcycles, boats, tractors, and racing cars.
Technical Specifications
| Feature | Details |
| Brand | RANMEI |
| Rating | 30A 12V DC |
| Switch Type | SPST (Single Pole Single Throw) |
| Terminals | 3-Pin (Power, Load, Ground) |
| Mounting Hole | 12 mm (0.47″) |
| LED Color | Blue |
| Waterproof Rating | IP65 (with rubber cover) |
| Quantity | 3 Switches per Pack |
